| Measuring range | Trace range sensor | Wide range sensor |
| Oxygen in the gas phase | 0 hPa to 45 hPa | 0 hPa to 1,000 hPa |
| Dissolved oxygen | 0 ppm to 2 ppm | 0 ppm to 45 ppm |
| CO2[1] | 0 g/L to 8 g/L (0 vol. to 4 vol.) at 30 °C (86 °F)
0 g/L to 10 g/L (0 vol. to 5 vol.) < 15 °C (59 °F) |
| Temperature[2] | 0 °C to 40 °C (32 °F to 104 °F) for non-frozen samples |
| Pressure | 5 bar abs. to 6.2 bar abs. |
| Repeatability[3] |
| TPO | ±8 ppb or ±6 %, whichever is higher | ±25 ppb or ±6 %, whichever is higher |
| CO2[1] | 0.01 g/L (0.005 vol.) |
| Environmental conditions |
| Ambient temperature | 15 °C to 35 °C (50 °F to 95 °F), 0 °C to 40 °C (32 °F to 104 °F) on request |
Relative humidity
(non-condensing)[4] | 10 % to 90 % |
| Package dimensions |
| Package diameter | 35 mm to 90 mm (1.4 in to 3.5 in) |
| Package height | 30 mm to 370 mm (1.2 in to 14.6 in) |
| Package volume[5] | 150 mL to 2,000 mL |
| Tested packages and sample types[6] |
| Glass (without cork) | 12 oz, 14.5 oz, 18 oz, 22 oz, 22.4 oz, 24 oz, 32 oz, 40 oz | 250 mL, 330 mL, 750 mL, 1,000 mL |
| PET[7] | 42 oz | 1,000 mL, 1,500 mL |
| Aluminum bottle | 14 oz | 2,000 mL |
| Aluminum can | 8 oz, 10 oz, 12 oz, 16 oz, 25 oz | 330 mL, 500 mL |
| Typical sample types | All common styles of beer, cider, ready-to-drink (RTD) beverages, seltzer, water, wine, and carbonated non-alcoholic drinks (e.g., energy drinks and highly carbonated drinks on request). All samples must be non-pulp containing. |
| Further details |
| Gas consumption / measurement | Vn = 13 L |
| Required oxygen-free gases | N2 or CO2 class 5 (only with TPO 3001), 5 bar abs. to 6.2 bar abs. non-fluctuating (±0.1 bar abs.) |
| Water supply[8] | - Quality of water: deionized, chlorine-free, filter 150 μm (100 mesh)
- Pressure: 1.5 bar abs. to 4.5 bar abs. |
| Communication interfaces | 2x USB, Ethernet, CAN (for Anton Paar devices only), RS232 |
| Power supply | AC 85 V to 264 V, 47 Hz to 63 Hz or DC 120 V to 370 V |
| Display | 7'' LCD panel touch screen |
| Data storage | Up to 5,000 measurement data sets |
| Degree of protection | IPX3 |
| Dimensions (L x W x H) | 515 mm x 590 mm x 1,120 mm (20.3 in x 23.2 in x 44.1 in) |
|
| Weight | 70 kg (154 lbs) |
| Altitude | Max. 2,000 m |
